CB12RF RF Multizone Control Box

Name: CB12RF RF Multizone Control Box - Salus Global
SKU: CB12RF

Features include a pump output, boiler module, and heat/cool changeover.

Features input for an external antenna to enhance RF performance.

Controls 12 zones, 24 actuators, and expands with 8 slave units.

Supports Zigbee 3.0 for seamless smart home integration.

Features a 230V pump output, a volt-free boiler module, heat/cool .changeover (CO) functionality

Product Type	Wiring Centre
Mounting Type	Flush mounting & Din Rail
Power Supply	230V
Suitable for underfloor heating	Yes
Compatible with SALUS Smart Home devices	Yes
Controlled via internet	Yes
Output Voltage	230V / Volt Free
Dew point terminal	Volt free
Cooling mode function	Yes
Maximum amperage	5A
Number of room thermostats	12
Number of Actuators	24
Warranty	5 years
Dimensions (mm)	240 x 80 x 55
Quick installation / connection	Yes
Stand-alone functioning	Yes
Master-slave functionality	Yes
Zigbee Technology	Zigbee 3.0
Support period end date	2030-12-31
Support period	5 years
