INV-WF-8000W-1P Single Phase Inverter

Quick and easy installation –manuals available in English and dedicated technical support for commissioning.

Monitor the inverter’s performance directly from the SALUS Premium Lite app for complete and efficient control of the photovoltaic system.

Advanced protection against islanding, insulation resistance detection, residual current monitoring, and protection against overcurrent, short circuit, and overvoltage, for safe and reliable operation.

Top certifications – compliant with international and European standards IEC, VDE, EN, and local regulations

TECHNICAL SPECIFICATIONS

Available in	UK
Photovoltaic panels	Details
Maximum nominal power	12 kW
MPPT Trackers	2
Number of inputs per MPPT	2 + 1
Maximum current per MPPT tracker	16 A
Batteries	Details
Voltage range	40-58V
Max. charging current	160 A
Grid/Home Input/Output	Details
Number of phases	1
Nominal output power	8kW
Output voltage	230V
General	Details
Protection class	Back-up Output Short Protection, Insulation Resistor Detection, Island Protection, Output Over Current Protection, Output Over Voltage Protection, Output Under Voltage Protection, Residual Current Monitoring Unit
Size (mm)	484.5 / 467 / 200
Weight	22Kg
Warranty	10 years or 4000 cycles
