CB500CO Wired control box 230V (5 zones)

This control box is the main element of the underfloor heating/ cooling system.

Easy wiring.

Allows you to control 5 different zones.

The spring clamps provide quick and convenient wiring connections.

Equipped with 230V voltage outputs for a pump and zone valve.

Available in	France, Germany, Italy, Netherlands, Spain, UK
Product type	Wiring Centre
Mounting type	Flush mounting & Din Rail
Power supply type	230V
Suitable for underfloor heating	Yes
Output voltage	230V
Warranty	5 years
Cooling mode function	Yes
Size (mm)	270x110x55
Voltage	230V
Maximum amperage	7 (2) A
Input voltage	230V
Works with NO and NC actuators	Yes
Can connect up to "n" actuators per zone	6/2/4/4/4
Number of room termostats	5
Number of Actuators	20
Dew point terminal	Volt free
Earth terminal for power supply/circulation pump	Yes
